Planar VM Series
Planar® VM Series LCD video wall displays provide a feature-rich, ENERGY STAR® certified solution for always-on and high-ambient light applications. It offers high reliability to meet the demands of digital signage applications such as retail, hospitality, corporate lobbies, casinos and museums.
- 55″ Full HD LCD display
- 0.88mm tiled bezel width
- 700-nit brightness
- 24×7 reliability
Overview
Planar VM Series Models
| Explore by Model: |
 Diagonal |
 Tiled Bezel Width |
 Resolution |
 Brightness |
|---|---|---|---|---|
| VM55MX-M2 | 55″ / 139cm | 0.88mm | 1920×1080 | 700 nits |
Specifications
| Product Name | VM55MX-M2 |
|---|---|
| Planar Part Number | 998-2595-00 |
| Viewable Size | 55″ diagonal |
| Display Technology | Commercial-grade IPS LCD |
| Backlight | D-LED with Local Dimming |
| Brightness (Typical) | 700 cd/m² |
| Bezel Width | 0.44mm even |
| Tiled Bezel Width | 0.88mm |
| Display Resolution | 1920 x 1080, full HD |
| Aspect Ratio | 16:09 |
| Contrast Ratio (typ) | 1100:1 |
| Contrast Ratio – Dynamic | 140,000:1 |
| Response Time (typ) | 8 ms |
| Viewing Angle (typ) | 178° |
| Palette | 1.073B colors (10 bit) |
| Color Gamut | 72% NTSC |
| Pixel Pitch | 0.630mm x 0.630mm |
| Haze | 28% |
| External Connections | DisplayPort 1.2 in x 1, DisplayPort out, HDMI 2.0 in x 2 (HDCP 2.2), OPS x 1, OPS USB 2.0 x 2, OPS USB 3.0 X 1, VGA in x1 |
| Display Control | IR, RS232, LAN, HDMI-CEC, Keypad |
| Audio Input | Phone jack |
| Audio Output | Phone jack, S/PDIF |
| Display Active Area | 47.6″ x 26.8″ (1209.6mm x 680.3mm) |
| Display Dimensions w/Handles | 47.7″ x 26.8″ x 4.0″ (1210.5mm x 681.2mm x 101.8mm) |
| Display Dimensions w/o Handles | 47.7″ x 26.8″ x 3.8″ (1210.5mm x 681.2mm x 97.1mm) |
| Mount | VESA 400mm x 400mm |
| Orientation | Landscape/Portrait |
| Display Weight | 52 lb (23 kg) |
| Weight (Shipping) | 76 lb (35 kg) |
| Features | OPS slot, on/off scheduling, up to 10×10 video wall scaling, carrying handles |
| Speakers | 10W x 2 built-in |
| Enclosure | Metal |
| Fanless | Yes |
| Line Voltage | 100-240V; 49/61Hz |
| Power Consumption (typ) | 115W |
| Operating Temperature | 0-40°C (32 -104°F) |
| Operating Relative Humidity | 20-85% |
| Service and Support/Warranty | 3-year Advance Exchange |
| Recommended Usage | Up to 24×7 operation |
| Product Approvals | FCC Class A, cTUVus, CE, RoHS |
| ENERGY STAR Certified | Yes |
| In the Box | VM55MX-M2 display, 1.8m AC Power Cord (US), 1.8m AC Power Cord (EU), 1.8m DisplayPort cable, Remote control, IR Receiver, IR loop cable, RS-232 cable, RS-232 loop cable, alignment brackets, cable clips, Quick Start Guide |
